SPEEDYSCAF

The Steel Deck LW

Using higher-tensile steel grades, a thinner material and an intelligent combination of profiles and material concentrations at structurally relevant areas, it has proved possible to reduce the weight of the steel deck, already established in the market, by up to 2.2 kg or 10 % – while retaining its high load-bearing capacity. That makes this steel deck lighter, handier and more effective. Discover the benefits that the steel deck LW from Layher has to offer: Because Layher Lightweight is about more than just weight.

• Can be used up to load class 6 (≤ 2.07 m) and in standard and roof brick guards.
• Better grip thanks to optimised steel cap and to the new longitudinal profile, ensuring more ergonomic handling and greater safety.
• Weight saving of up to 10 % while retaining a high load-bearing capacity – meaning lower labour costs, an increase in truck capacity and improved ergonomics.
• Strong feeling of safety when walking on the decks thanks to transverse reinforcements in the surface.
• Can be combined with steel decks of previous generations during assembly and transport.

Anchoring

The scaffolding must be anchored vertically to and parallel with the façade, with resistance to both tensile and compressive stress. Layher offers quicker and safer solutions:

The SpeedyScaf wall tie, which is fastened by a double coupler in the corner plate area of the Speedy assembly frame Lightweight and is supported with the fork plate on the channel section of the Speedy assembly frame Lightweight.

The wall tie, which is connected with two double couplers to both upright tubes.

The SpeedyScaf Corner Plate Coupler
For outside and inside brackets, continuous anchoring directly on the corner plate of the Speedy assembly frame Lightweight using the top hole is possible and ensures a greater height clearance at the top scaffolding level.

The ETICS tie is used for a controlled introduction of high forces, parallel to the facade, when using thermal insulation compound systems.

The Speedy Vario wall tie system permits structurally favourable anchoring anywhere inside the scaffolding level, even outside the connectors of the assembly frames, for example in buildings with many windows, skeleton structures or in similar situations.

Roof Brick Guards

Roof brick guards must be used when there is any risk of slipping on the roof, and they are mandatory for a roof inclination of 20° and above. Either brick guards or protection nets can be attached to the brick guard support.

Stairway Access

The aluminium platform and comfort stairways offer increased safety, convenience and speed when ascending the tower. Transporting material is made easier by using the work decks as all-round walkways too.

Stairways are highly recommended when:

• extensive amounts of material have to be transported via this access,
• the ascent height in the scaffolding exceeds 10 m, or
• extensive work has to be carried out.

The landing-type stairway is connected using the U-distance coupler to the main scaffolding.

Protective Roofs

Layher weather protection roofs can be used in a number of variants depending on their span, the snow load or the wind load. That saves you real money when planning temporary weather protection roofs. For easy use on the site, clearly set-out material and loading capacity tables for snow and wind loads are available for you. Protective roofs are not a one-off solution for Layher, but a standard product – this ensures readiness for immediate delivery.

Protect System

With its Protect System, Layher offers an enclosure system that fits in with Allround Scaffolding and SpeedyScaf. It is used for example for pedestrian protection in combination with the Allround Bridging System and also for environmental protection and noise reduction. Highly economical to use thanks to quick and easy assembly in a simple and logical assembly sequence, and the frequent use of a few system components. The Layher Protect System is not a one-off solution for Layher, but a standard product – this ensures readiness for immediate delivery.

• Only a small number of individual parts.
• Designed for regular use.
• Visually attractive.
• Quick, easy and logical assembly.
